[ ISV.F-50 ]
Multicusp Positive Ion Source
Low-Current Positive Ion Source • Filament-Driven Multicusp • TRIUMF Licensed
[ Ion Sources ]
ISV.F-50
Multicusp Positive Ion Source · TRIUMF Licensed
The D-Pace Multicusp Positive Ion Source is based on TRIUMF licensed technology and offers a compact, versatile platform for positive ion beam production. The source can be configured for hydrogen, helium, deuterium, and other gaseous ion species, with permanent multicusp magnets, intuitive tuning, long filament life, and simple maintenance supporting dependable operation.
Beam Intensities
| Ion Species | Beam Current (mA) | Beam Energy (keV) | Notes |
|---|---|---|---|
| H+ | 0-3 | 20-30 |
Ion Source Characteristics
| Particle Types | H+, H2+, H3+ |
|---|---|
| Beam Kinetic Energy | 30 keV |
| Normalized Emittance | < 0.5 mm·mrad |
| Beam Purity | > 90% (for H+) |
| Beam Current Stability | ±1% over 24 hours |
Vacuum System
| Turbo Pump Speed | 2200 L/s |
|---|---|
| Turbo Pump Flange | ISO250 |
| Roughing Pump Capacity | 36 m3/h |
Gas Flow
| Mass Flow Controller | 1-10 sccm |
|---|
Controls
| Control PLC | Allen-Bradley |
|---|---|
| User Interface Options | Custom web-based interface, EPICS compatible |
| HV Interlocks | Safeguards designed in accordance with ISO 13849 |
Power Supplies
| Supply | Current | Voltage / Power |
|---|---|---|
| Max Bias Supply | 40 mA | 30 kV |
| Arc Supply | 50 A | 300 V |
| Filament Supply | 510 A | 10 V |
| Extraction Electrode | 10 mA | -4 kV |
| Suppression Electrode | 10 mA | -3 kV |
| X & Y Steering Magnet (2 per system) | 60 A | 20 V |
Maintenance
| Filament Lifetime | > 5250 mA∙hours |
|---|
Product Images
Dr. Anand George
Ph.D
Lead Physicist
Included
- Ion Source & vacuum box
Optional
- Turnkey ion source system or any sub-components
- LEBT components
- Diagnostic devices
